Isolated DCDC Converter 75 kW

DC Converter 75 kW

Our DCC75i allows the bidirectional connection of DC-Loads or sources.

The main applications is charging of electric vehicles or battery storage systems. It is also possible to create isolated DC-Grids.

By connecting several units in parallel a system power of up to 1.5 MW can be realized easily.

Nominal input voltage 200 V / 1000 V
Rated power 75 kW
Output voltage 200 V – 1000 V
Rated output current 100 A @ 750 V
Efficiency >99 %
Dimensions 132 x 1059 x 240 mm
Weight < 50 kg
Use Case: 1500 V DC Service station network
